Introduction

    Efficient hydraulic cone crusher wide range of materials from limestone to basalt , from stone production to various ore crushing, efficient completion of a variety of pieces, fine , super fine crushing . Mine construction industry today replace spring cone crusher and the general hydraulic cone crusher to replace the latest generation of products , is a large stone factory and ore crushing the best equipment.

Works

    Working cone crusher is moving mosaic liner composed of cone and fixed cone . During normal operation of the machine , the cone and the cone of the movable toward and away from , the material in the crushing chamber to promote crushing and be crushed by the breaking action , and fall under its own weight , the crusher discharge chamber . Moving cone of the upper chamber is supported on the upper end of the spherical bearing fixed spindle , set in the eccentric sleeve outside its lower chamber , the movement driven directly by the eccentric sleeve . When the eccentric sleeve rotates around the axis , moving cone not only with the center line of the eccentric sleeve rotates around the machine , but also around their own axis. The cone is moving around the center of its spherical bearing for space spin pendulum movement.

Product Features
1 , crushing ratio, high production efficiency ;

2 , the vulnerability of low consumption , low operating cost ;

3 , laminating crushing, excellent finished grain type ;

4 , Hydraulic protection and hydraulic cavity clearing , high automatic degree , reduce the closure time ;

5 , lubrication , reliable and advanced to improve life ;

6 , a variety of crushing cavity , flexible , adaptable ;

7 , easy maintenance , easy operation .
